GDE043A2 is an Active Matrix Electrophoretic Display(AM EPD), High-Resolution AM TFT Black/White display
module can be used in portable electronic devices, such as E-book Reader.
The module is a TFT-array driving electrophoretic display, with integrated circuits including source and gate drivers.
The resolution of the module is 800×600（SVGA), and the active area is 4.3 inch diagonal.
· Parallel interface
· Partial refresh
· 800x600 resolution
· Come with helpful development resources and manual (STM32 platform )
|
Part Number
|
GDE043A2
|
|
Type
|
Dot Matrix
|
|
Resolution
|
800*600
|
|
Outline Size(mm)
|
126.5*74.6*1.17
|
|
Active Size(mm)
|
88*66
|
|
Pixel Pitch(mm)
|
0.11*0.11
|
|
Operating Temp.
|
0℃~+50℃
|
|
Storage Temp.
|
-25℃~+70℃
|
|
Contrast Radio
|
above 8:1
|
|
Color
|
Black, White
|
|
Max Grayscale
|
16
|
|
Power consumption of the refresh(mW) |
600 |
|
Standby power consumption Pc(mW) |
0.4 |
|
Full refresh(s) |
1 |
|
Partial refresh(s) |
1 |
|
Purchase Online |
buyepaper / AliExpress
|
If you want to buy the set: e-paper and matched demo, please click here: With Drive Board
Development Board
Q:Can this e-paper support partial refresh?
A:Yes.
|
