Your present location:Home >> TFT LCD Panel >> 5" TFT LCD Panel - GTI050NA-08C
  • Product Name: 5" TFT LCD Panel - GTI050NA-08C
  • Code: 7050-1
  • Quantity in stock: Yes
  • Retail price: 35.00USD
  • Unit of measurement: pcs
  • Net weight:
  • Views : 2026





Click to buy NOW!

Size 5inch
Resolution 640x480
Display scale 4:3
Luminanc 200 nits
Contrast Ratio 500 :1
Color 262K(6bit)
Technology a-Si
Pixel Pitch 0.0529x0.1587 mm
Active Area 101.57(W) × 76.18(H) mm
Outline 117.65x88.43x5.7mm
Viewing Angle 70/70/50/70 (U/D/L/R)
Backlight LED
Operation Temperature -20oC ~ 70oC
Storage Temperature -30oC ~ 80oC
Applications Multimedia



We can provide the matched driver board for VGA/Video input.

What should I notice when using the lcd panel?

Please see following important safety instructions:

1. The nominal voltage of DC input to the A/D board is 12V, The size of DC current depends on the TFT    LCD panel, audio amplifier, etc. Please note that your AC/DC adapter's output plug need to match the DC input jack, the diameter of the jack is 5.5 mm.

2. Before connecting these input/output ports, Video port, it is strongly recommended that your turn off the     A/D board and remove the DC 12V plug from the DC input jack.

3. Don’t put the A/D board into an airtight package. When it works, it will produce a certain heat.

4.  When assembling it, please use a suitable force; don’t distort the PCB and other components.







File Type
Documents Name (Downloadable)
Update Date
File Size









How do your factory control the quality?

quality assurance--.jpg




All Products of Good Display can be provided in small quantities with long term supply.  Products are complete, with quality assurance.
Welcome to order.


download attachments : GTI050NA-08C specification 【查看】
